Specifications
Nominal Diameter: 1″ (25mm)
Suction Port: Rc 1
Discharge Port: Rc 1
Supply Port: Rc 3/8
Exhaust Port: Rc 3/4
Operating Air Pressure: 0.2 ~ 0.7 MPa
Maximum Discharge Pressure: 0.7 MPa
Discharge Volume / cycle * 1: 600ml | 450ml
Slurry Limitation: 3mm max.
Weight: 9.2kg
